VTL Series

(Model Variants: VTL 400 / VTL 500-5,7 / VTL 750)

To meet the requirement of heavy engineering industries such as Oil & Gas, Earth Moving, Automobile VTL series machines delivers its best. Graded cast iron bed and column assures thermal stability and better machine life accuracy along with great rigidity, stability and performance. Box type construction, heavy duty spindle, high speed bi-directional servo turret and wider box guide ways assures vibration free cutting. VTL finds its wide application for machining of bigger diameter heavy component like valve body, motor body, break drum, disc brake etc.

VTL Series
Download Brochure Make an Inquiry General Catalogue

Features

Key Features

  • Heavy and rigid single piece structure.
  • Heavy duty box type guide ways.
  • Rigid saddle and ribbed column structure.
  • High performance heavy duty spindle.
  • Counter balance Z axis.
  • Bi-directional 8-station high precise fast servo turret.
  • Live tool turret available for milling operations
  • Hydraulic chucking.
  • Auto and manual coolant system.
  • Electrical with quality devices & panel with A.C.
  • Centralized & programmable lubrication.
  • Rear side efficient chip disposal from centre of bed.
  • Easy accessibility for job loading from top and front.
  • Ergonomic design and improved operating features.

Monoblock Rigid Structure

3-point Levelling

Bi-directional servo turret

90° Tilting operator panel

TPM Friendliness

Technical Specification

    VTL 400 VTL 500/5A VTL 500/5B VTL 500/7A VTL 500/7B VTL 750A VTL 750B
Capacity
Swing Dia. mm 625 720 720 720 720 900 900
Std. Turning Dia. mm 400 500 500 500 500 750 750
Max. Turning Dia* mm 420 500 500 500 500 750 750
Max. Turning Length* mm 410 500 500 750 750 750 750
Slides
X-Axis (Horizontal) mm 225 265 265 265 265 400 400
Z-Axis (Vertical) mm 410 500 500 750 750 750 750
Feed
Rapid (X/Z Axis) m/min 24 20 20 20 20 20 20
Cutting Feed m/min 10 10 10 10 10 10 10
Main Spindle
Chuck Size mm 250 315 400 315 400 400 530
Range of Table Speed rpm 3000 2500 2000 2500 2000 2000 1200
Front Bearing Dia. mm 100 120 160 120 160 160 200
Spindle Nose   A2-6 A28 A211 A28 A211 A211 A215
Spindle Motor Power - Fanuc kW 15/11 18.5 /15 22/18.5 18.5 /15 22/18.5 22/18.5 22/18.5
Spindle Motor Power - Siemens kW 15.6/12 27.8/18.5 27.8/18.5 27.8/18.5 27.8/18.5 27.8/18.5 42/28
Gear Box   Opt. Opt. Std. Opt. Std. Std. Std.
Tool Turret
Type of Turret   Servo Servo Servo Servo Servo Servo Servo
No. of Tool Station   8 8 8 8 8 8 8
Tool Size mm 25 x 25 25 x 25 32 x 32 25 x 25 32 x 32 32 x 32 32 x 32
Boring Bar Dia. mm 50 50 50 50 50 60 60
Accuracy (as per VDI/DGQ 3441)
Positioning Uncertainty(P) mm 0.01 0.015 0.015 0.015 0.015 0.015 0.015
Repeatability (Ps Medium) mm 0.005 0.007 0.007 0.007 0.007 0.007 0.007
Other Data
Machine Weight # (Approx) kg 5500 8000 8200 8500 8700 10500 10700
Machine Dimension # (Approx)
Length mm 1600 3010 3010 3010 3010 3980 3980
Width mm 1750 1715 1715 1715 1715 2075 2075
Height mm 2450 3185 3185 3185 3450 3490 3490
* Depend upon clamping arrangement, Tooling & Job
# Refer machine detailed layout
